ELEGLIDE
T1

100km
Top Range

25km/h
Max Speed

3.5"
LCD Display

50Nm
Torque

27.5"x2.1"
CST Tires

7 Speed
Shimano Gear

5 Levels of
Pedal Assist

6km/h
Push Mode

Strong Motor,
Powerful Runner
Driven by a 250W brushless motor with 50Nm torque,
it can speed up to 25km/h.Enjoy your powerful and
exciting ride with Eleglide T1!
250W
Power
50NM
Torque


Larger Battery,
Longer Ride
The 450Wh large battery supports up to 100km
in assist mode, perfect for your long ride!

The max range is achieved with a 75kg load and a constant speed of 15km/h on
flat roads without strong winds at 26°C.

5 Levels of
Pedal Assist

12km/h

16km/h

20km/h

23km/h

25km/h

Bigger Tire,
Smoother Tour
With a 27.5" big size, the CST pneumatic tires roll
smoothly on different road surfaces. Go on a
smooth bike tour with Eleglide T1!
Multiple Speeds,
Multiple Fun
The 7-speed Shimano gear provides variable speed
that gets you more fun in cycling.


Smart Panel,
Easy Control
The intelligent display shows you various information
and also
allows you to charge your phone through its USB port

Speed

Assist Level

Battery Level

Light-on Mark

Brake Mark

Malfunction Mark

Trip Time

Riding Distance

Front Suspension
with Lockout
The upgraded suspension comes with lockout.You
can lock it on flat roads and unlock it on bumpy
paths for a comfortable touring ride.
Note: suspension travel: 80mm

Sturdy Rack,
Cozy Trip
The rear rack is sturdy enough to hold
your luggage, enabling you to have a
cozy trip with Eleglide T1!
More Details

Bright LED Headlight

Dual Disc Brakes

Premium Gear Protector

Cozy Foam Saddle
[Specification]
General
- Brand:ELEGLIDE
- Type:Trekking Bike
-
Model:T1
- Color:Black
- Material:Aluminum Alloy
Specification
- Suspension:Mechanical Damping with Lockout
- Motor:250W (Rated Voltage 36V; Ins Max Power 500W; Max Output Torque 50N.M)
- Motor Brand:ANADA
- Battery:450Wh, 36V 12.5Ah Support Protect System
- Max Range:100KM (Assist Mode)
- Max Speed:25 km/h
- Charger Output:42V 2A
- Charging Time:4-6h
- Derailleur:Shimano Gear 7 Speeds (Rare)
- Maximum Load:120kg
- Recommended height of cyclists:160-200cm (5.25ft-6.56ft)
- Height of Saddle:825mm-1000mm
- Waterproof Rate:IPX4
- Brake System:Front & Rear Disc Brakes + Auto Power-off Design
- Front & Rear Brake: Mechanical Disc-160mm Rotor
- Tires:CST 27.5"*2.1" Pneumatic Tires
- Fork: Hydraulic with Lockout-80mm travel
- Display:3.5" LCD
5 Speed Mode | Weight & Size |
Speed 1: 12 km/h | Gross Weight: 30.5KG |
Speed 2: 16 km/h | Net Weight: 26KG |
Speed 3: 20 km/h | Package Size: 148x25x83cm |
Speed 4: 23 km/h | Unfolded Size: 179x68x112cm |
Speed 5: 25 km/h |
Handlebar Width: 66cm |
|
Package Contents
- 1 x E-Bike
- 2 x Pedals (Right&left)
- 1 x Charger
- 1 x Tool Kit
- 2 x Keys
- 1 x Spoke Reflector
- 1 x Taillight
- 1 x Headlight
- 1 x LCD Display
- 1 x User Manual
[/Specification]
General
- Brand:ELEGLIDE
- Type:Trekking Bike
-
Model:T1
- Color:Black
- Material:Aluminum Alloy
Specification
- Suspension:Mechanical Damping with Lockout
- Motor:250W (Rated Voltage 36V; Ins Max Power 500W; Max Output Torque 50N.M)
- Motor Brand:ANADA
- Battery:450Wh, 36V 12.5Ah Support Protect System
- Max Range:100KM (Assist Mode)
- Max Speed:25 km/h
- Charger Output:42V 2A
- Charging Time:4-6h
- Derailleur:Shimano Gear 7 Speeds (Rare)
- Maximum Load:120kg
- Recommended height of cyclists:160-200cm (5.25ft-6.56ft)
- Height of Saddle:825mm-1000mm
- Waterproof Rate:IPX4
- Brake System:Front & Rear Disc Brakes + Auto Power-off Design
- Front & Rear Brake: Mechanical Disc-160mm Rotor
- Tires:CST 27.5"*2.1" Pneumatic Tires
- Fork: Hydraulic with Lockout-80mm travel
- Display:3.5" LCD
5 Speed Mode | Weight & Size |
Speed 1: 12 km/h | Gross Weight: 30.5KG |
Speed 2: 16 km/h | Net Weight: 26KG |
Speed 3: 20 km/h | Package Size: 148x25x83cm |
Speed 4: 23 km/h | Unfolded Size: 179x68x112cm |
Speed 5: 25 km/h |
Handlebar Width: 66cm |
|
Package Contents
- 1 x E-Bike
- 2 x Pedals (Right&left)
- 1 x Charger
- 1 x Tool Kit
- 2 x Keys
- 1 x Spoke Reflector
- 1 x Taillight
- 1 x Headlight
- 1 x LCD Display
- 1 x User Manual
Dimension


- A. Total Length: 70.5 inch
- B. Handlebar Height: 41 inch
- C. Wheelbase: 43 inch
- D. Min Seat Height: 32.5 inch
- E. Max Seat Height: 39.5 inch
- F. Standover Height: 30 inch
- G. Effective Top Tube: 23.4 inch
- H. Wheel size: 27.5 inch
- I. Down Tube: 29.4 inch
- J. Seat Tube: 17.5 inch
- K. Angle: 53.6°
