Assembly Guide

T1 & T1 STEP-THRU

Assembly video

Assemble Eleglide T1 & T1 STEP-THRU

Assembly steps

Step 1: Install The Handlebar

  1. A) Take out the bike and make it stand up.
  2. B) Open the clip by loosing the screws on it.
  3. C) Place the handlebar in the right position and make sure the clip is in the middle of the bar.
  4. D) Lock the clip by tightening the screws.

    Step 2: Install The Front Wheel

    1. A) Put the bike upside down and remove the temporary protected bar by loosing the nut on it.
    2. B) Insert the front wheel into the fork dropouts and make sure the wheel is fully seated.
    3. C) Remove the nut and one spring on the quick release.
    4. D) Slide the quick release through the hub from the opposite side of the brake disc.
    5. E) Slide the spring into the hub and tighten the nut to fix the quick release.

    Step 3: Fix The Headset

    1. A) Adjust the headset of the bike to the right position.
    2. B) Tighten the headset with the M4/M5 socket head wrench.

    Step 4: Adjust The Stem Angle (Only for T1 Step-Thru)

    1. A) Loose the stem with the M6 socket head wrench.
    2. B) Adjust the stem to the angle you want and fix it by tightening the screws.

    Step 5: Install The Headlight

    1. A) Place the headlight in the right position.
    2. B) Fix the light by tightening the screw with the M4 socket head wrench.

    Step 6: Install The Taillight

    1. A) Connect the wire to the taillight.
    2. B) Place the taillight in the right position and tighten the screws to fix it.

    Step 7: Fix The Mudguard

    1. A) Fix the support of the mudguard by tightening the screws with the M5 socket head wrench.

    Step 8: Install The Pedals

    Step 9: Install The LCD Display

    1. A) To make it easy to install, disassemble one of the supports of the display first with the M3 socket head wrench.
    2. B) Slightly open another support to get the display stuck on the handlebar.
    3. C) Slightly open the disassembled support and buckle it on the handlebar. Fix it with the M3socket head wrench.
    4. D) Fix the display in the middle of the handlebar with the M3 socket head wrench.
    5. E) Open the clip of the display button and buckle it on the handlebar. And use the M2.5 hex wrench to tighten the clip and fix the button.
    6. F) Connect the display cable with the power cord.

    Note: don’t overtighten screws when you install the display. Or it will cause permanent damage to it. The display can be mounted firmly with 0.2N.m torque.

    Step 10: Install Spoke Reflectors

    Step 11: Install The Seat

    1. A) Slide the seat post into the support frame.
    2. B) Adjust the seat to a suitable height and fix it by tightening and locking the quick-release clip.

    Step 12: Turn The Power on

    1. A) Lock the battery and turn the display on. Then it’s ready to go!



    M1, M1 Plus, F1:

    Assembly video

    Assemble Eleglide M1 PLUS/M1

    Assemble Eleglide F1

    Assembly steps

    Step 1: install the front wheel

    • A) Take out the bike and make it stand up.
    • B) Loose the nut to remove the temporary protected bar.
    • C) Insert the wheel between the fork blades so that the axle can seat firmly at the fork dropouts (the slots at the tip of the fork blades).
    • D) Put the gaskets on it and tighten up the nuts.

    Note: if the lever cannot be pushed all the way to a position parallel to the fork blade, return the lever to the OPEN position. Then turn the tension adjusting nut counterclockwise and make a one-quarter turn, and try tightening the lever again.

    Step 2: adjust the stem

    • A) Undo the stem bolts slightly till you can turn the stem.
    • B) Align the stem with the front wheel.
    • C) Tighten up the stem bolts.

    Step 3: install the handlebar

    • A) Undo the handlebar clamp bolts to open the clamp.
    • B) Place the handlebar and make sure the clamp is in the middle of the handlebar. (The brake levers should be in front of the grips.)
    • C) Tighten up the clamp bolts to lock the clamp.

    Step 4: install the front light

    • A) Place the front light with the fork brace.
    • B) Secure the light by tightening up the bolt.

    Step 5: install the pedals



    Step 6: install the seat

    • A) Slide the seat post into the support frame.
    • B) Adjust the seat to a suitable height and fix it by locking the quick-release clip.

    Step 7: install the battery

    • A) Put the battery in place as the picture shows.

    Step 8: install the reflectors

    Step 9: turn the power on

    • A) Press the on/off button on the battery to turn the battery on.
    • B) Press the on/off button on the display to turn the power on. Then it’s ready to go!



    E-scooters:

    Assembly video

    Assemble S1/S1 PLUS

    Assemble D1/D1 Master

    Assembly steps

    Eleglide e-scooters all come in an easy-to-install pack. The assembly steps are as follows.



    Step 1

    Get it out and unfold it

    1. Get the scooter out of the box and press down the folding lever a bit to unfold the handlebar stem and fasten it.
    2. Unfold the kickstand to support the e-scooter and lift up the handlebar.



    Step 2

    Assemble the display

    1. Place the display on the right handlebar and fasten it in the right position with the tool in the package.





    Step 3 (Only for D1)

    Assemble the saddle

    1. Lift up the seat post and fasten it with the nut.
    2. Twist the nut to get the seat post ready for the saddle.
    3. Loose the quick release clip.
    4. Put the saddle in the seat post and keep the saddle at a suitable height, then tighten the clip.



    Step 4

    Turn the power on

    1. Put the key into the keyhole and rotate it to get the power supply. (Please take care of the key.) Then the scooter is ready for your first ride.
