ELEGLIDE
M2
Hydraulic
Suspension
25km/h
Cut-off Speed
L: 29"x2.4"
Hydraulic
Disc Brakes
24 Speed Shimano Gear
5 Levels of Pedal Assist
App & Display
Controls
The large Kenda pneumatic tires adapt to more road surfaces, making the bike a smoother runner even on rough terrain.
M: 27.5"x2.35" Size
L: 29"x2.4" Size
Hydraulic disc brakes offer better control and greater braking effort and tend to last longer than traditional mechanical brakes.
Mighty Runner
The brushless motor delivers 55Nm torque
and enables a max speed of 25km/h. Enjoy a
powerful and exciting ride with Eleglide M2.
570W Max Power 55NM Torque
with Lockout
The front hydraulic shock absorber with a lockout provides you with a more comfortable and smoother ride.
Suspension Travel: 100mm
Larger Battery, Longer Ride
The large 540Wh removable battery supports up to 125km in assist mode, perfect for your long ride!
125KM Assist Mode
The max range is achieved with a 75kg load and a constant speed of 15km/h on flat roads without strong winds at 26°C.
More Gears, More Fun
The 24-speed Shimano gear lets you revel in the thrill of variable speed and elevates your riding experience to new heights of enjoyment.
24 Gears
LCD Display, Easy Control
Battery Level
Assist Level
Speed
Malfunction
Riding Distance
Light Mark
Walk Mode
Brake Mark
Smart App, Smart Ride
More functions can be activated through
the smart Eleglide app. It is available on
Apple iOS (11.0+) and Android devices (5.0+).
Light
Speed
Lock
Reset
Smart App, Smart Ride
More functions can be activated through
the smart Eleglide app. It is available on
Apple iOS (11.0+) and Android devices (5.0+).
Light
Speed
Lock
Reset
Smart App, Smart Ride
More functions can be activated through
the smart Eleglide app. It is available on
Apple iOS (11.0+) and Android devices (5.0+).
Light
Speed
Lock
Reset
5 Levels of Pedal Assist
12km/h
16km/h
20km/h
23km/h
25km/h
12km/h
16km/h
20km/h
23km/h
25km/h
User-Friendly Details
Rear Reflector
Bright LED Headlight
Cozy Foam Saddle
Removable Battery
GENERAL | |
---|---|
Brand: | Eleglide |
Type: | Mountain Bike |
Model: | M2 |
Color: | Black |
SPECIFICATION | |
---|---|
Net Weight: | M-22kg; L-23kg |
Unfolded Size: | M-1800x680x1060mm; L-1865x680x1070mm |
Size of Frame: | M-27.5"x18"; L-27.5"x18" |
Length of Handlebar: | 680mm(26.8", without grip covers), 700mm(27.6", with grip covers) |
Height of Saddle (from the ground): | M-34.3"-41.7"; L-35.4" "-42.9" |
Recommended Rider Height: | M-160-195cm (around 5' 3"-6' 4.8"); L-170-200cm (around 5' 7"-6' 7") |
Max Load of Bike: | 120 kg |
Cut-off Speed: | 25km/h |
Max Range: | 125km (Assist Mode) |
Pedal Assist Levels: | 12/16/20/23/25 km/h |
Walk Mode: | 6km/h |
Waterproof Level: | IPX4 |
Material: | Aluminium Alloy (AL6061) |
Braking System: | Hydraulic Disc Brakes & Power-off Design |
Motor | |
---|---|
Rated Voltage: | 36V |
Max Instantaneous Power: | 570W |
Max RPM: | M-250; L-231 |
Max Output Torque: | 55N.M |
Battery | |
---|---|
Capacity: | 15Ah |
Voltage: | 36V |
Charging Time: | 10h |
Power Capacity: | 540Wh |
Protection System: | Yes |
Charger | |
---|---|
Input: | 90~264V, ≤2.2A |
Output: | 42V, 2A |
Tires | |
---|---|
Brand: | Kenda |
Size: | M-27.5"x2.4"; L-29"x2.4" |
Type: | Pneumatic Rubber Tires |
Tire Pressure: | 40-65PSI |
Best Tire Pressure: | 50PSI (Front), 55PSI (Rear) |
Display | |
---|---|
Size: | 1.75" |
Type: | LCD |
Information: | Speed, Battery Level, Trip Distance/Odometer, Assist Level, Push Mode, Light Mark, Error Code, Brake/Malfunction Mark |
Functions: | Power on/off, turning light on/off, shifting assist levels, activating walk mode, removing ODO data, setting screen timeout, etc. |
App | |
---|---|
Name: | Eleglide |
System Support: | iOS (11.0+), Android (5.0+) |
Functions: | Turning light on/off, shifting assist levels, locking/unlocking the bike, setting a password, adjusting screen brightness, etc. |
Download the App: | Search “Eleglide” from App Store and download |
Package | |
---|---|
Size: | M-1480x240x770mm; L-1500x230x790mm |
Gross Weight: | M-27.5kg; L-31kg |
Package Contents | |
---|---|
1 x E-Bike | 1 x User Manual |
1 x Charger | 2 x Pedal |
1 x Rear Reflector | 4 x Spoke Reflector |
1 x Headlight | 1 x Saddle | 1 x LCD Display | 2 x Key | 1 x Tool Kit |
GENERAL | |
---|---|
Brand: Eleglide | Type: Mountain Bike |
Model: M2 | Color: Black |
SPECIFICATION | |
---|---|
Net Weight:
M-22kg; L-23kg | Unfolded Size:
M-1800x680x1060mm; L- 1865x680x1070mm |
Size of Frame:
M-27.5"x18"; L-27.5"x18" | Length of Handlebar: 680mm(26.8", without grip covers), 700mm(27.6", with grip covers) |
Height of Saddle (from the ground): M-34.3"-41.7"; L-35.4" "-42.9" | Recommended Rider Height: M-160-195cm (around 5' 3"-6' 4.8"); L-170-200cm (around 5' 7"-6' 7") |
Max Load of Bike: 120 kg | Cut-off Speed: 25km/h |
Max Range: 125km (Assist Mode) | Pedal Assist Levels: 12/16/20/23/25 km/h |
Walk Mode: 6km/h | Waterproof Level: IPX4 |
Material: Aluminium Alloy (AL6061) | Braking System: Hydraulic Disc Brakes & Power-off Design |
Motor | |
---|---|
Rated Voltage: 36V | Max Instantaneous Power: 570W |
Max RPM: M-250; L-231 | Max Output Torque: 55N.M |
Battery | |
---|---|
Capacity: 15.6Ah | Voltage: 36V |
Charging Time: 10h | Power Capacity: 540Wh |
Protection System: Yes |
Charger | |
---|---|
Input: 90~264V, ≤2.2A | Output: 42V, 2A |
Tires | |
---|---|
Brand: Kenda | Size: M-27.5"x2.4"; L-29"x2.4" |
Type: Pneumatic Rubber Tires | Tire Pressure: 40-65PSI |
Best Tire Pressure: 50PSI (Front), 55PSI (Rear) |
Display | |
---|---|
Size: 1.75" | Type: LCD |
Information: Speed, Battery Level, Trip Distance/Odometer, Assist Level, Push Mode, Light Mark, Error Code, Brake/Malfunction Mark | Functions: Power on/off, turning light on/off, shifting assist levels, activating walk mode, removing ODO data, setting screen timeout, etc. |
App | |
---|---|
Name: Eleglide | System Support: iOS (11.0+), Android (5.0+) |
Functions: Turning light on/off, shifting assist levels, locking/unlocking the bike, setting a password, adjusting screen brightness, etc. | Download the App: Search “Eleglide” from App Store and download |
Package | |
---|---|
Size: M-1480x240x770mm; L-1500x230x790mm | Gross Weight: M-27.5kg; L-31kg |
Package Contents | |
---|---|
1 x E-Bike | 1 x User Manual |
1 x Charger | 2 x Pedal |
1 x Rear Reflector | 4 x Spoke Reflector |
1 x Headlight | 1 x Saddle |
1 x LCD Display | 2 x Key |
1 x Tool Kit |
Dimension
M2 27.5"
A. Total Length: 70.9" | B. Handlebar Height: 42.5" | |
C. Wheelbase: 43.3" | D. Min Seat Height: 34.3" | |
E. Max Seat Height: 41.7" | F. Standover Height: 31.1" | |
G. Effective Top Tube: 41.7" | H. Wheel Size: 27.5" | |
I. Down Tube: 27.5" | J. Seat Tube: 18" | |
K. Angle: 53.4° | L. Steering Bar: 27.2" | |
M. Reach: 16.2" | N. Stack: 23.7" | |
O. Head Tube Angle: 71° |
A. Total Length: 70.9" | B. Handlebar Height: 42.5" | |
C. Wheelbase: 43.3" | D. Min Seat Height: 34.3" | |
E. Max Seat Height: 41.7" | F. Standover Height: 31.1" | |
G. Effective Top Tube: 41.7" | H. Wheel Size: 27.5" | |
I. Down Tube: 27.5" | J. Seat Tube: 18" | |
K. Angle: 53.4° | L. Steering Bar: 27.2" | |
M. Reach: 16.2" | N. Stack: 23.7" | |
O. Head Tube Angle: 71° |
M2 29"
A. Total Length: 72.8" | B. Handlebar Height: 42.5" | |
C. Wheelbase: 43.7" | D. Min Seat Height: 35.4" | |
E. Max Seat Height: 42.9" | F. Standover Height: 32.4" | |
G. Effective Top Tube: 23.8" | H. Wheel Size: 29" | |
I. Down Tube: 28.3" | J. Seat Tube: 19" | |
K. Angle: 51.2° | L. Steering Bar: 27.2" | |
M. Reach: 16.4" | N. Stack: 24.9" | |
O. Head Tube Angle: 71° |
A. Total Length: 72.8" | B. Handlebar Height: 42.5" | |
C. Wheelbase: 43.7" | D. Min Seat Height: 35.4" | |
E. Max Seat Height: 42.9" | F. Standover Height: 32.4" | |
G. Effective Top Tube: 23.8" | H. Wheel Size: 29" | |
I. Down Tube: 28.3" | J. Seat Tube: 19" | |
K. Angle: 51.2° | L. Steering Bar: 27.2" | |
M. Reach: 16.4" | N. Stack: 24.9" | |
O. Head Tube Angle: 71° |
